Zero Latency Fiber Optic HDMI Extender with 10km Transmission 4K60 Resolution and KVM RS232 Support

Product Categories
Shenzhen Bitvisus Technology Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Zero Latency Fiber Optic HDMI Extender with 10km Transmission 4K60 Resolution and KVM RS232 Support

Brand Name : Bitvisus

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us

Model Number : BIT-Ex-Fib-4K-KVM

Certification : CE,HDMI,HDCP,RoHS,FCC

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 135mm x 85mm x 25mm

Material : Metal

Interface protocol : HDMI 1.4, HDCP1.4 Compliant DVI1.0, VGA

Maximum Pixel Clock Rate : 297MHz

Supported Resolution : 4096x2160P30

Bandwidth : 10.2Gbps

Color Depths : 24bit

Color Format : RGB444, YUV444

Audio : HDMI Audio Follow-On Out

KVM : Keyboard, Mouse

RS232 Range : Adaptive within 800M

Product Dimensions : 135mm x 85mm x 25mm

HDMI Version : HDMI 2.0b

HDMI Resolution : 4K/60Hz

Max Bandwidth : 600MHz

Max Baud Rate : 6Gbps

Contact Now

Zero Latency Fiber Optic HDMI Extender
Professional 10km uncompressed 4K60 HDMI extension solution with KVM and RS232 support, ideal for stadiums, theme parks, and large-scale venues.
Advanced Features
  • 4K Ultra HD: Maximum resolution up to 4096x2160@30Hz with full backwards compatibility
  • Long-Distance Extension: Zero latency, uncompressed signal transmission up to 10km
  • High Bandwidth: 10 Gbps data transfer rate for high-speed transmission of large volume data
  • EDID Management: Lock and pass-through functionality
  • Multi-Function Interface: HDMI/HDCP1.4, USB, and more
  • USB Passthrough: KVM functions for keyboard and mouse control
  • Bidirectional RS232 Communication: Remote two-way data transmission for enhanced control and monitoring
  • Note: RS232 and USB interfaces - choose one to use
  • Plug & Play: Compact form factor, rugged design, easy installation with no software drivers required
  • Strong Anti-Interference: Unaffected by electromagnetic interference for stable signal transmission
  • Eco-friendly & Energy-efficient: Low power consumption with CE, RoHS, FCC certifications
    Zero Latency Fiber Optic HDMI Extender with 10km Transmission 4K60 Resolution and KVM RS232 Support
Typical Applications
Remote Monitoring Systems, Digital Signage, Medical Imaging, Performance Venues, Movie Theaters, Stadiums, Large Meeting Rooms, Lecture Halls, and more.
Contact Our Team
Welcome to consult about your project function requirements!
Technical Specifications
HDMI Version HDMI 2.0b
HDMI Resolution 4K/60Hz
Support Video Format 3D
Support Video Color Format 24/30/36 bit deep color
Support Audio Format DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
Max Bandwidth 600MHz
Max Baud Rate 6Gbps
Input Cable Distance ≤8m AWG26 HDMI standard cable (4K/30HZ); ≤3m 2.0 HDMI standard cable (4K/60HZ)
Output Cable Distance ≤8m AWG26 HDMI standard cable (4K/30HZ); ≤5m 2.0 HDMI standard cable (4K/60HZ)
Max Working Current 350mA
Power Adapter Format Input AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature Range -10 to +55℃
Dimensions (L x W x H) 136x80x22 (mm)
Weight 118g
Zero Latency Fiber Optic HDMI Extender with 10km Transmission 4K60 Resolution and KVM RS232 Support
Frequently Asked Questions
Why Choose Bitvisus?
  • Own warehouse ensuring shipping within 48 hours after payment (weekends and holidays excluded)
  • OEM/ODM services available for custom requirements
  • Leading manufacturer in the fiber optic extension field
How to Order
  • Contact us via email, chat, TM, WhatsApp, or Skype with your order requirements
  • We provide proforma invoice based on your order request
  • After payment confirmation, goods are delivered promptly
Warranty & After-sale Service
  • 12 months warranty with lifetime service support
  • Return or exchange available for faulty, damaged, or wrong model items
Shipment & Payment
  • Payment methods: T/T, Visa, PayPal, Western Union, L/C
  • Shipping options: DHL, UPS, EMS, FedEx, Air freight, Sea freight
    Zero Latency Fiber Optic HDMI Extender with 10km Transmission 4K60 Resolution and KVM RS232 Support
